Specifications Download Specifications Download as PDF Video & Audio Image Sensor 1/2.8" CMOS sensor Video Resolution Default: 3840*2160 (8 megapixels) @25FPS Lens f=2.8-8mm, F=1.6, with IR Cut Video Format H.265 Field of View • Horizontal: 94°- 50° • Vertical: 53°- 30° Day & Night IR-cut filter with auto-switching Infrared Night Vision 30 meters (2pcs/28mil/850nm) Color Night Vision 1pcs/4.7W/6500K/700lm Audio Two-way audio Power PoE IEEE 802.3af, 48V active DC Power DC 12.0V?1A, <12W Interface Power DC power port System Reset button Ethernet One 10M/100Mbps RJ45 Storage MicroSD card slot (max. 256GB) Audio Built-in microphone and speaker Software Features Frame Rate • Mainstream: 2fps - 25fps (default: 25fps) • Substream: 4fps - 15fps (default: 10fps) Code Rate • Mainstream: 4096Kbps -8192Kbps (default: 6144Kbps) • Substream: 64Kbps - 512Kbps (default: 256Kbps) Browser Supported Edge, Chrome, Firefox, Safari OS Supported PC: Windows, Mac OS; Smartphone: iOS, Android Smart Alarm Motion detection, person detection, vehicle detection, pet detection (beta) Record Mode Motion recording (default), scheduled recording, 24/7 recording Protocols & Standards HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P Maximum User Access 20 users (1 admin account and 19 user accounts); 12 simultaneous video streams (10 substreams and 2 mainstreams) Work with Google Assistant Working Environment Operating Temperature -10°C~+50°C (14°F~122°F) Operating Humidity 10% ~ 90% Waterproof IP66 Size & Weight Dimension F117.4 x 103.8mm Weight 510g |
